BALANCE+

AMPLIFICATION  1 KHZ 44 dB (MM mode)
63 dB (MC mode)
INPUT IMPEDANCE 47 kOhm / 220 pF / MM mode
510 Ohm / 220 pF / MC mode
MM / MC INPUT switchable (on bottom panel)
RIAA delay time: 75 μs / 318 μs / 3180 μs
RIAA ACCURACY ± 0.1 dB
DISTORTION 0.001% (IEC A)
SIGNAL TO NOISE RATIO 89 dB (MM Mode)
74 dB (MC Mode)
CHANNEL SEPARATION > 92 dB (@ 1 kHz) / opposed channel hot-wired
MAX. OUTPUT VOLTAGE 10.5 V (@ 1 kHz)
SUBSONIC FILTER 20 Hz: –3 dB / Oct
POWER SUPPLY ± 18 V DC (external power supply)
OUTPUT CONNECTIONS Unbalanced (RCA)
Balanced (XLR)
POWER CONSUMPTION Max. consumption: 6.6 Watt
Consumption in operation: 6.6 Watt
Off mode: 0.0 Watt (turned off at rear panel)
TOTAL WEIGHT Approx. 1.8 Kg (Preamplifier)
Approx. 2.5 kg (Power supply)
DIMENSIONS (W/D/H in inches) Preamp: 7.09 x 8.66 x 2.17
Power Supply: 7.09 x 7.28 x 2.17
DIMENSIONS (W/D/H in mm) Preamp: 180 x 220 x 55
Power Supply: 180 x 185 x 55
