The Ortofon’s MC Anna represents the highest echelon of Moving Coil cartridges. This state of the art product, representative of numerous Ortofon design elements and ideals, is truly exemplary of the highest degree of performance possible in contemporary analogue playback technology.
| Brand |
|---|
Output voltage at 1000 Hz, 5cm/sec. – 0,2 mV
Channel balance at 1 kHz – 0,5 dB
Channel separation at 1 kHz – 25 dB
Channel separation at 15 kHz – 22 dB
Frequency response – 20 Hz-20.000 Hz +/- 1.5 dB
Tracking ability at 315Hz at recommended tracking force – 80 µm
Compliance, dynamic, lateral – 9 µm/mN
Stylus type – Special polished Nude Ortofon Replicant 100 on Boron Cantilever
Stylus tip radius – r/R 5/100 µm
Tracking force, recommended – 2,6 g (26 mN)
Tracking angle – 23°
Internal impedance, DC resistance – 6 Ohm
Recommended load impedance – > 10 Ohm
Cartridge body material – SLM Titanium
Cartridge colour – Black/Silver
Cartridge weight – 16 gram
