XA100.8

SKU: XA100.8 Category:

Description

The middle sibling of the XA.8 series, the XA100.8’s realize a muscular yet highly refined sonic profile. Like all Pass Laboratory’s power amplifiers, they features both single-ended and balanced inputs, Furutech five-way binding posts and a convenient ground terminal for safe subwoofer connection. Improved constant-current sourcing, precise voltage references and current-feedback all represent new benchmarks in state-of-art amplifier design. The result is a larger, more realistic soundstage, sharper transient response and the prized ability to reach concert-hall dynamics and realism without strain.

Additional information

Brand

Technical specifications
Class
A
Type
Mono
Gain (dB)
26
Full Pwr @ 26 dB gain (V)
1.41
Low Frequency Response
1.5 Hz
High Frequency Response
100 KHz
Power Output /ch (8 ohm)
100
Distortion (1 KHz, full power)
1%
Input Impedance (SE & BAL Kohms)
50/100
Damping Factor
200
Output Noise (uV)
200
Current Draw @ Idle (Amps)
3.5
Power Consumption (Watts)
420
Temperature (deg C.)
53
Number of Chassis
1
Unit Dimensions (W x D x H) (In.)
19 x 21.25 x 9
Unit Weight (LBS)
99
